Esophageal atresia (EA) is a common and important congenital anomaly of pediatric surgical practice affecting one in 2,500 to 4,500 live births. Tracheoesophageal fistula (TEF) is defined as congenital fistulous connection between esophagus and airway. EA and TEF may be presented together or less commonly presented as separate malformations (1,2). All newborns with EA need immediate surgical repair of this anomaly. Following the first successful repair of EA which was performed by Haight and Towsley in 1941 (3), the survival rate has improved up to 95% thank to advances in neonatal intensive care and anesthesia. As more patients reach adulthood, more studies focus on the long-term complications of EA repair.
The main complications of EA repair are classified as early and late complications. Anastomotic leak, stricture and recurrent TEF (recTEF) are the early complications, whereas gastroesophageal reflux, esophageal dysmotility, tracheomalacia and respiratory disorders are the late ones (1,2,4,5). TEFs seen after EA repair are the most challenging complication for both patient and the surgeon. The fistulas between esophagus and airway can be congenital, recurrent, missed, or acquired. Not only the diagnosis of all these fistulas is difficult, but also the management is still challenging since secondary surgeries causes increased risk for secondary recurrences, increased morbidity and even mortality (6). In this review, it is aimed to discuss the diagnosis, treatment and outcome of all types of TEFs in children.
Definition and classification of TEF
The standard approach to the repair of EA and TEF is well described which consists of ligation of fistula and primary anastomosis of esophagus. Although EA repair has usually excellent outcome, several post-operative challenging situations may come through including fail of repair, need for lengthening procedures, need for revisional surgeries, and several defined complications (4,7). Among those, the fistula occurrence after primary repair of EA is one of the most challenging complications (4). A fistula can occur after EA repair because of the recanalization of ligated original TEF, a de novo fistula with different location or a second congenital fistula missed at the primary surgery (8). Overall, incidence of fistula recurrence is between 5–10% (9). Although the clinical presentations of these recurrent fistulas are similar, several differences might be existing regarding the management of these fistulas. Based on this point, Smithers et al. suggested a new classification of the fistulas occurred after EA repair (9). They classified postoperative fistulas as recTEF, missed TEF (mTEF) and acquired TEF (acqTEF) (9). RecTEF is defined as the fistula recurred at the original TEF location. MTEF is the second congenital fistula, actually a proximal fistula missed at the primary repair. AcqTEF is defined as a de novo fistula between esophagus and airway at a new location. AcqTEFs include all new connections between esophagus or colonic and gastric conduit and any level of airway such as trachea, bronchia, or pulmonary parenchyma (9). The acqTEFs secondary to EA-TEF repair will be discussed in this review. AcqTEFs due to cancer, trauma and other causes are not included in the scope of this review.
Although the surgical outcome of EA and TEF repair is mostly satisfying, a small but important portion of patients needs secondary or revisional surgery. Most of these secondary surgeries are need to be performed for recurrent fistulas. Zhu et al. also reported that 76% of the patients with EA were re-operated for recTEF (10).
There are several well-described risk factors of recTEF. These risk factors can be listed as inadequate ligation of original TEF, anastomotic complications including leak, stricture and ischemia, tracheal injuries at the primary repair, and juxtapositioning of esophageal and tracheal suture lines (1,6,11). It would be beneficial to be aware of these risk factors in order to decrease the recTEF incidence.
Pathogenesis of recTEF
In open repair of EA and TEF, the fistula is closed with sutures and divided which is an important step in preventing recurrence of fistula. However, in thoracoscopic repair, the fistula is usually ligated with titanium clips (12). A recent systematic review about thoracoscopic repair of EA revealed that the preferences for fistula ligation was suture in 30% of cases, and clips with/without sutures at the rest of the cases (12). In the same review, the endoclip displacement was seen in two of nine complicated cases, whereas fistula recurrence was seen in 5.3% of cases (12). On the other hand, Schlesinger et al. reported a case whose primary repair was performed thoracoscopically, and diagnosed as recTEF because of migrated clips (13). Although their recurrence rate is low, they emphasized the possibility of recTEF in cases with migrated clips in chest radiogram (13). Additionally, there are several studies reporting that there is no significant difference regarding recTEF incidence between open and thoracoscopic repair (14,15).
The complications of esophageal anastomosis are important risk factors for fistula recurrence. Anastomotic leak after primary repair of EA possibly cause local or diffuse mediastinitis leading to breakdown of tracheal closure and causing recTEF (14,16,17). In a retrospective cohort study, 26 cases with recTEF were reported and 18 of them (68%) were reported to have experienced anastomotic leak after the primary repair (16). In a multi-institutional retrospective cohort study, recTEF occurred in 5% of the cases and univariate analysis revealed that anastomotic leak was significantly associated with increased risk of recTEF with OR of 4.26 (1.47–12.3, P=0.007) (14). The multivariate analysis in the same study also revealed significantly increased risk of recTEF in anastomotic leak with OR of 5.03 (95% CI: 1.14–22.3, P=0.033) (14). Interestingly, the authors emphasized that placement of prosthetic material between suture lines increases anastomotic leak incidence, but did not cause difference in the incidence of recTEF (14).
The tissue damage at the anastomotic site is another important cause of recTEF. This tissue damage might be seen because of tissue ischemia, tensioned anastomosis, early or forced dilatation of esophageal strictures (6,18). Briganti et al. also stated that esophageal dilatation in severe stricture may be a risk factor for recTEF (19). However, their results are not statistically significant. Although it is reasonable that aggressive dilatation might cause leaks, tissue damage and eventually recTEF, it seems that future prospective studies are needed to confirm this issue. Similarly, juxtapositioning of esophageal and tracheal suture lines is considered a risk factor for recurrence (18,19). Therefore, the interposing various tissues such as pleura, pericardium, intercostals muscle are recommended to prevent recurrence of fistula (6,18,19).
Diagnosis of recTEF
The diagnosis of recTEF is also challenging. The patients with EA very commonly experience several respiratory symptoms such as coughing, chocking or recurrent respiratory tract infections (1,6,7,11). Since all of the patients either with gastroesophageal reflux, tracheomalacia or recTEF experience similar symptoms, it is difficult to distinguish which of the EA-related complications is the cause of these symptoms. Therefore, all patients having coughing, chocking or recurrent respiratory tract infections after EA repair should be investigated for the presence of recTEF.
The diagnostic modalities include esophagogram and bronchoscopy (6,7,11). The routine esophagogram may miss recTEF very commonly. Therefore, prone pull-back method should be used to visualize a recTEF (11). The most appropriate way to visualize a recurrent fistula is to pass a tube down to esophagus and then to push the tube while giving contrast agent in prone position (11,16). Nevertheless, both diagnosis and precise localization of the fistula could not be possible even with prone pull-back esophagogram. Therefore, bronchoscopy should be performed to confirm the diagnosis and localize the fistula (16). Additionally, placing a catheter into the fistula through the working channel of the bronchoscope and then pulling it from the esophagus, and fixing it in place would provide an easier dissection of fistula during the surgery (16). In some occasions such as presence of very small pit or presence of irregular fistula tract due to increased fibrosis, catheterization of fistula would not be possible. In this case, methylene blue test, applying methylene blue from the opening and checking esophagus whether methylene blue passed or not, can be performed (6,16,20). Most authors suggest using rigid bronchoscope in order to confirm diagnosis and place the guiding catheter. However, Hotta et al. suggested to perform flexible bronchoscopy and flexible esophagoscopy to localize the fistula in cases that exact diagnosis could not be achieved with rigid bronchoscopy (20).
Management of recTEF
Once the diagnosis of recTEF was made, historically open surgical repair was the only option for management. The open surgical management consists of localization, re-ligation and division of the recurrent fistula and interposing a viable tissue between suture lines via thoracotomy (6). The periesophageal and peritracheal inflammation and fibrosis in the re-operated field makes the open repair challenging (6,21). Waiting at least 5 weeks after the initial repair is recommended for resolution of the inflammation in the operation field (21).
Traditionally, open approach for recTEF is suggested performing via a right-sided thoracotomy since the recTEF is expected to be localized at the original TEF site (7,21). However, in a few study, it has been reported that in cases with severe mediastinal inflammation and fibrosis, transtracheal route or median sternotomy route are alternative approaches (21-23). The esophageal replacement can also be performed in cases operated for several times and had multiple recurrences as a last choice of management (6). On the contrary, some authors encourage thoracoscopic approach for better visualization and accurate dissection in surgical management of recTEF (24). Since thoracoscopic approach has several advantages, it should be kept in mind especially for the patients whose primary repair was also performed thoracoscopically.
Many authors recommend interposing a viable tissue between suture lines in order to prevent a secondary recurrence of fistula (6,21). Vascularized pleura, pericardium and intercostal muscle flaps are most commonly used tissues for interposing (19,21). Moreover, costal cartilage graft could also be used especially in cases that were experienced tracheal injury in the initial surgery (25). The other rarely used are omental flap (26) and combination of free auricular and fascia lata graft (27). There is no literature data supporting one tissue in preventing fistula recurrence.
The major complications of open repair of recTEF are leak and secondary recurrence of TEF. The possibility of complications and rate of mortality increases especially in patients having associated esophageal stricture (7). In rare instances, various reconstructive procedures may be needed to restore the esophageal continuity. However, mostly open repair of recTEF has excellent outcomes, and usually does not require more than two times of re-operation (21).
The challenges in open repair of recTEF led many authors to perform endoscopic management as first line therapy of recTEF (6,21). The endoscopic management techniques are classified into three main categories; obstruction of fistula tract, de-epithelization of the tract, combination of de-epithelization and obstruction of tract (6,21). The commonly used agents for obstruction of tract are fibrin glue and n-butyl cyanoacrylate, and less commonly biosynthetic mesh (21,28,29). The de-epithelization can be accomplished with mechanical abrasion, electro-cauterization, laser ablation, chemocauterization and sclerosing (18,30-33). According to the literature, there is no superiority of any technique to another (6). All of these procedures require bronchoscopy with or without esophagoscopy. The patients should not be fed orally for a few days and control esophagogram should be undertaken before oral feeding (Table 1).
|Open repair||93% success rate||20% re-fistula formation|
|Mostly single operation||16% leak|
|Endoscopic management||67–84% success rate||Mostly multiple procedures|
|20% re-fistula formation|
|5% respiratory distress|
|Obstructing fistula (fibrin glue, n-butyl cyanoacrylate, biosynthetic mesh)||48–55% success rate||Migration risk|
|De-epithelization (mechanical abrasion, electro-cauterization, laser ablation, chemocauterization, sclerozing)||45–60% success rate||Tracheal injury risk|
|Thermal damage risk|
|Combination therapies (fistula obstruction and de-epithelization)||67–84% success rate||–|
|Better success rates|
recTEF, recurrent tracheoesophageal fistula.
Although there is exceeding number of studies in the literature regarding the endoscopic management of recTEF, most of the studies are case series or retrospective studies with small number of subjects. The overall success rate ranging between 60% and 74%, low complication rates and less morbidity, and easily re-applicability makes the endoscopic procedures preferred choice of management (6,18,21). However, endoscopic procedures are not free of complication. The most terrifying complications are respiratory distress due to migration and aspiration of sealant or injury to trachea during cauterization (21,29). In addition, multiple procedures are performed to achieve the aforementioned success rates (21). This brings multiple hospitalizations, increased cost, and increased pulmonary morbidity. A recent systematic review revealed that open repair has higher success rates, lower morbidity and mortality and less number of procedures than endoscopic approach (21). Although endoscopic treatments are good alternative for selected cases, the treatment failures should be considered.
Persistent respiratory symptoms after EA repair are mostly caused by a recTEF. However, some of them are actually more proximal fistula missed at the primary repair of EA. According to the Gross classification of EA, the incidence of Gross type-A (isolated EA) is 8%, type-B (proximal fistula with distal atresia) is 1% and the incidence of type-D (proximal and distal fistula) is 1%. Notably, presence of a proximal fistula should not be underestimated especially in patients who were initially diagnosed as isolated EA (34). Even more, some authors reported the incidence of missed proximal fistula as 4% to 6% in their study (34,35).
The pre-operative diagnosis of a proximal fistula is difficult, because the diagnosis of EA with distal fistulais usually made by a plain radiogram with nasogastric tube only or the amount of contrast is not suitable enough to fill the proximal fistula. Therefore, bronchoscopy is considered as the gold standard test in diagnosis of proximal fistula (34-36). During bronchoscopy, some identifying characteristics should be considered in order to make diagnosis properly (34). The proximal fistulas are usually located very close to vocal cords and have very small orifice, so a careful examination of upper trachea is mandatory (34). The best way to show a proximal fistula during bronchoscopy is insufflation of air from esophagus (34).
In recent studies, 3D CT and virtual bronchoscopy are reported to be useful in diagnosis of mTEF (37). Although it is a useful technique to confirm the diagnosis and show the concurrent problems such as tracheomalacia, the radiation risk is very high especially in pediatric population. Instead, performing bronchoscopy to all patients with EA is recommended to prevent delay in diagnosis.
The definition ‘acqTEF’ is a little bit confusing since it has usually used to define the fistulas that are seen secondary to foreign body ingestion or iatrogenic trauma (38,39). However, Smithers et al. classified the new TEF with a long and different location that is seen after EA repair as acqTEF (9). The location of these fistulas is different from the original TEF location. They have long new pathway extending from any part of airway including trachea, bronchia and lung parenchyma to esophagus or the replaced conduit (9,40).
The diagnosis of acqTEF is challenging because of its unusual location (Figure 1). It is usually difficult to demonstrate the fistula and mostly impossible to cannulate during bronchoscopy because of tortuous and irregular border of fistula tract and abnormal location of the orifice (40).
Once the diagnosis is confirmed, the management of fistula should be performed surgically (9). However, there are some studies revealing that there is a possibility of spontaneous healing of acquired fistula (38,40). The probable cause of spontaneous healing is thought to be due to ongoing inflammation ad fibrosis that helps to the closure of abnormally located fistula tract. Therefore, active observation for 6–12 weeks is recommended before surgical management in order to help healing and improve surgical dissection by allowing decrease in inflammation at the operation field (38,40).
Based on this literature review, the patients having persistent respiratory symptoms should be examined for possible recTEF, mTEF and acqTEF. Although the clinical presentation of all post-operative TEF is similar, the diagnostic modalities and management approaches may vary. Therefore, a prompt diagnosis and accurate classification of post-operative TEF may improve long-term morbidity and mortality of these patients.
